Thumbnail Filmstrip of 5.25" 150W Trimless In-Wall LCR Center Channel Speaker w/ Dual Carbon Fiber Woofer, Single - IW550 Images
The OSD IW550 in-wall LCR (left, right, center) trimless speaker is an economical and space-saving option for adding left, center and right channels to a home theater or media room. This in-wall LCR speaker can be used as a center-channel speaker in a surround-sound stereo or as a right or left speaker in a high-end system and complete your design looks.The dual carbon-glass fiber cone woofers produce clear, full bass tones with smooth high-frequency roll-off, while the 1" aluminum dome tweeter gives you distortion-free sound on the high end. The IW550 is capable of handling up to 150 watts so it can be paired with robust sound systems, and it's easy to install with the included template.
- Space-saving in-wall speaker with 150W of power handling
- Can be used as a left, right, or center speaker
- Dual Carbon-Glass Fiber Cone Woofers for excellent low and mid-range frequencies
- 1" aluminum dome for clean and clean and clear high notes
- Easy to install with included template
- Paintable frame and grille blends with the design of any room
Why Go Trimless?
It's really a matter of aesthetic preference. These flush mounted speakers are hardly noticeable; that is until they're playing. Our trimless speakers do not include the 3/4-inch trim you typically see around in-wall speakers. The micro flange grilles are attached by extremely powerful magnets that stay put for quick and easy installation. Adds less visual impact on your architectural audio installation.
Why Choose In-Wall Speakers Over Regular Speakers?
Typically, rectangular in shape in-wall speakers are mounted in the wall and take up far less space than traditional box speakers. Customers love that wires are neatly concealed behind the wall and OSD in-walls can even be painted to match a room décor. Most in-wall speakers use the wall cavity as their enclosure or cabinet, which explains why in-wall must be installed to sound right. In-wall speakers come with special screws (called dog ears) that flip out and secure to the drywall (or other wall surfaces), a nearby stud, or a special frame attached to the studs. Custom installation frames (brackets) can also be purchased for a more secure fit or for lighter wall materials that require more support. In wall speakers are often categorized by the size of the woofer, not the size of the speaker itself.
What Type of Speaker Wire and What Gauge?
Wiring is not included with in-wall speakers so you will have to purchase some. We recommend our OSD Audio CL3/FT4 cable that is UL (fire) rated for in-wall and outdoor speaker installs. This type of cable includes a heavy-duty outer jacket approved for in-wall/in-ceiling installation. The high-quality plastic jacket is also very flexible so it's easy to run the wires inside the wall. As for the gauge, for runs up to 100 feet for background music, 16-gauge will be fine. If the run is approaching or exceeding 100 feet, we suggest 14-gauge wire.
What Is Butyl Rubber Surround?
With almost double the shelf life of foam, butyl rubber has been the choice of speaker designers looking to optimize the sound based upon materials that go together. The Surround is just one of the integral parts of the speaker's motor structure. Butyl Rubber gives the speaker more excursion capability featuring a deeper bass with a wider frequency response, and its shelf life is closer to 25 years compared to the foam at 12 to 15 years.
Installation Tips: Carefully plan the layout of your home theater system, as speaker installation requires that you cut a hole in your wall.
For a retrofit installation, no construction bracket is needed.
- Speaker Type: 5.25" In-Wall LCR Speaker
- Woofer: Dual 5.25" Carbon & Glass Fiber Cone
- Tweeter: 1" Ceramic Coated Aluminum
- Frequency Response: 57Hz-20kHz
- Power Handling: 150 Watts
- Sensitivity: 87 dB 1w/1m
- Impedance: 8 Ohms
- Inputs: Spring Binding Posts
- Install-friendly Dog Ear Installation Brackets
- Paintable Grille Included
- Left, Center, Right Application
- Magnetically Shielded
- Sold As: Single
- Mounting Depth (Assuming .5" Drywall): 3.7"
- Unit Dimensions: (L x H x D) 15.6" x 7.5" x 3.75"
- Cutout Dimensions: (L x H) 14.3” x 6.25"
- Weight: 9 lbs
- Warranty: 10 Years
