    High-Fidelity 70V Audio Kit – 5.25" Patio Speakers w/ 50W Commercial Amplifier, Black or White

    Thumbnail Filmstrip of High-Fidelity 70V Audio Kit – 5.25" Patio Speakers w/ 50W Commercial Amplifier, Black or White Images

      Purchase High-Fidelity 70V Audio Kit – 5.25" Patio Speakers w/ 50W Commercial Amplifier, Black or White

      High-Fidelity 70V Audio Kit – 5.25" Patio Speakers w/ 50W Commercial Amplifier, Black or White

      SKU: KIT-PAX50-AP520T-PAR

      Color:

      Simplify your next commercial audio install with this ready-to-go 70V speaker and amplifier kit, ideal for small to mid-size distributed systems. This bundle includes two 5.25" outdoor 70V speakers and a 50W 70V/100V Class D amplifier—perfect for background music or paging in patios, entryways, restaurants, and retail storefronts.

      The IP54-rated speakers are built for covered outdoor use and include multiple 70V tap settings for easy system scaling. Full-motion brackets allow flexible mounting, while the compact 1U rack-mount amplifier offers RCA, AUX, and a balanced mic input. With simple tone controls and a line-level pre-out for expansion, this kit is a reliable, plug-and-play solution for efficient installations.

      Features:

      • All-in-one solution for commercial 70V distributed sound
      • Weatherproof speakers with full-range audio for outdoor use
      • Efficient Class D amp with multiple input options for paging or music
      • Works with both 70V and 100V commercial systems
      • Ideal for courtyards, storefronts, restaurants, and more
      Read More
      Read Less


      Technical Specifications

      AP520:

      • Speaker Type: 5.25" Indoor/Outdoor Patio Speaker
      • Enclosure Rating: IP54-rated composite cabinet with powder-coated aluminum grille
      • Drivers: 5.25" Polypropylene Woofer + 0.5" PEI Dome Tweeter
      • Frequency Response: 50Hz – 22kHz (±10dB)
      • Power Handling / Sensitivity: 20–120W / 88dB
      • Impedance & 70V Taps: 8 Ohms with built-in 70V transformer (32W, 16W, 8W, 4W)
      • Connections & Mounting: Gold-plated spring-loaded terminals with included 'U' bracket
      • Dimensions / Weight: 9.5" x 7" x 6.4"; 7 lbs each

      PAX-50:

      • Power Output: 50W @ 70V or 100V, Class D efficiency
      • Inputs: RCA, 3.5mm line-in, and 1/4" mic input with volume control
      • Frequency Response: 100Hz – 20kHz (+1dB/-5dB) for speech and background music
      • Signal-to-Noise Ratio: 80dB for clean, low-noise performance
      • Output Options: 70V/100V speaker output via Phoenix connector with selectable switch
      • Control Features: Front-panel master volume + individual gain knobs for Line 1 & 2
      • Form Factor: Compact metal chassis (6.24" x 10.09" x 1.9"); optional rack-mount kit
      • Certifications & Power: RoHS2, FCC, CE certified; external power supply (100–240V AC)
